Polyphenylene oxide (PPO) is one of the world's five general-purpose engineering plastics. It has the advantages of high rigidity, high heat resistance, flame retardant, high strength and excellent electrical properties. PPO has good flame retardancy and self-extinguishing properties: the oxygen index of PPO is 29, which is a self-extinguishing material. When making flame retardant PPO, halogen flame retardants are not required, and phosphorus-containing flame retardants can be added to achieve UL94 standard, thereby reducing environmental pollution.
Advantages of PPOs:
1. Low specific gravity, the lowest specific gravity in engineering plastics.
2. Good chemical corrosion resistance.
3. Excellent high and low temperature resistance, excellent mechanical properties.
4. High flow, excellent processability, superior surface gloss.
5. UL94 halogen-free flame retardant, no bromine and antimony, in line with EU halogen-free environmental protection requirements.
6. Over glow wire 850°C, good dielectric resistance, suitable for electrical applications.
7. Excellent weather resistance, good long-term performance, can be used for a long time in harsh weather
Product application: air conditioner electrical box, washing machine electrical box, electrical shell
1. It is suitable for making heat-resistant parts, insulating parts, wear-reducing and wear-resistant parts, transmission parts, medical and electronic parts.
2. It can be used as gears, fan blades, valves and other parts used at higher temperatures, and can replace stainless steel.
3. It can make screws, fasteners and connectors.
4. Electrical parts of motors, rotors, casings, and transformers.
Physical Properties |
Metric |
English |
Specific Gravity |
1.08 g/cc |
1.08 g/cc |
Moisture Absorption |
0.100 % |
0.100 % |
Linear Mold Shrinkage |
||
Mechanical Properties |
Metric |
English |
Tensile Strength, Yield |
44.0 MPa |
6380 psi |
Elongation at Break |
40 % |
40 % |
Flexural Strength |
64.0 MPa |
9280 psi |
Flexural Modulus |
2.30 GPa |
334 ksi |
Izod Impact, Notched |
1.18 J/cm |
2.21 ft-lb/in |
|
1.76 J/cm |
3.30 ft-lb/in |
Electrical Properties |
Metric |
English |
Volume Resistivity |
1.00e+16 ohm-cm |
1.00e+16 ohm-cm |
Surface Resistance |
1.00e+16 ohm |
1.00e+16 ohm |
Dielectric Constant |
2.9 |
2.9 |
|
2.9 |
2.9 |
Dielectric Strength |
29.0 kV/mm |
737 kV/in |
Dissipation Factor |
0.0030 |
0.0030 |
|
0.0040 |
0.0040 |
Arc Resistance |
100 sec |
100 sec |
Application range:
