Description
INEOS Terluran GP-22 is an ABS Resin grade.
Product Specification
| Property | Unit | Specification | Result | Test Method | ||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Melt Volume Rate | cm³/10 min | 220 °C/10 kg | 19 | ISO 1133 | ||||||||||||||||||||
| Izod Notched Impact Strength | kJ/m² | 23 °C | 26 | ISO 180/A | ||||||||||||||||||||
| Charpy Notched Impact Strength | kJ/m² | 23 °C | 22 | ISO 179/1eA | ||||||||||||||||||||
| Tensile Stress at Yield | MPa | 23 °C | 45 | ISO 527 | ||||||||||||||||||||
| Tensile Modulus | MPa | / | 2300 | ISO 527 | ||||||||||||||||||||
| Nominal Strain at Break | % | 23 °C | 10 | ISO 527 | ||||||||||||||||||||
| Flexural Strength | MPa | 23 °C | 65 | ISO 178 | ||||||||||||||||||||
| Hardness | MPa | Ball Indentation | 97 | ISO 2039-1 | ||||||||||||||||||||
| Vicat Softening Temperature VST/B/50 | ℃ | 50N, 50 °C/h | 96 | ISO 306 | ||||||||||||||||||||
| Heat Deflection Temperature A | ℃ | annealed 4 h/80 °C; 1.8 MPa | 94 | ISO 75 | ||||||||||||||||||||
| Thermal Conductivity | W/(m K) | / | 0.17 | ISO 22007-4 | ||||||||||||||||||||
Typical values should be confirmed against the latest producer-issued TDS before final use.
