PBT is a linear thermoplastic saturated polymer with bonds on its main chain. Its chemical name is Polybutylene Terehthalte, abbreviated as PBT, and it is a polymer of the same class as PET resin.
Because of its high melting point and crystallinity, low water absorption and coefficient of thermal expansion, it has excellent dimensional stability. In addition, it also has excellent electrical insulation, with minimal changes in electrical performance caused by moisture absorption and high insulation voltage. There are crystalline and amorphous regions in the aggregated structure of PBT, so it can be easily modified and endowed with various functions by adding other substances. The existing refractory grade, high-speed forming grade, and high impact resistance grade have been endowed with various functional grades. Connector, small switch, capacitor shell and other electronic parts, OA mechanical keyboard, VTR, telephone and other functional mechanical parts, automotive electronic parts, external door handle and other automotive parts. Furthermore, medical machinery, building materials, precision machinery, and other products are widely used in many of our daily necessities.
characteristic; The non reinforced grade is strong and flexible, with strong resistance to brittleness. It has UL specifications for flame retardant grade (94HB) and self resistant grade (94-V-0, V-2), and its electrical properties are the highest among thermoplastic materials. Extremely low water absorption, able to maintain excellent electrical performance over a wide range of temperature and humidity for long-term use. The surface of the molded product is very smooth and has a low coefficient of friction. Due to the small amount of friction generated, it is suitable for applications with requirements for friction and wear performance. The size change during use is very small, and it is a highly reliable material with excellent forming stability and dimensional accuracy. It has excellent long-term chemical resistance. At room temperature, except for drugs with strong alkalis, there is almost no performance degradation after long-term soaking. Not only the non enhanced grade, but also the enhanced grade has excellent fluidity and excellent molding and processing ability. By adopting technology that integrates with other polymers, polymer alloys that meet various performance requirements have been developed.
|
|||
Physical Properties |
Metric |
English |
Comments |
Specific Gravity |
1.29 g/cc |
1.29 g/cc |
ASTM D792 |
Maximum Moisture Content |
0.020 |
0.020 |
|
Linear Mold Shrinkage, Flow |
ASTM D955 |
||
|
|||
Mechanical Properties |
Metric |
English |
Comments |
Tensile Strength, Yield |
41.0 MPa |
5950 psi |
ASTM D638 |
Elongation at Break |
>= 25 % |
>= 25 % |
ASTM D638 |
Flexural Strength |
62.0 MPa |
8990 psi |
ASTM D790 |
Flexural Modulus |
1.931 GPa |
280.1 ksi |
ASTM D790 |
Izod Impact, Notched |
1.07 J/cm |
2.00 ft-lb/in |
ASTM D256 |
|
|||
Thermal Properties |
Metric |
English |
Comments |
Deflection Temperature at 0.46 MPa (66 psi) |
121 °C |
250 °F |
ASTM D648 |
Deflection Temperature at 1.8 MPa (264 psi) |
49.0 °C |
120 °F |
ASTM D648 |
|
|||
Processing Properties |
Metric |
English |
Comments |
Rear Barrel Temperature |
|
||
Middle Barrel Temperature |
|
||
Front Barrel Temperature |
|
||
Nozzle Temperature |
|
||
Melt Temperature |
|
||
Mold Temperature |
|
||
Drying Temperature |
121 °C |
250 °F |
|
Dry Time |
3.00 hour |
3.00 hour |
|
