The tensile strength, bending strength and other properties of PPS are at the middle level among engineering plastics, but the elongation and impact strength are very low. Therefore, when using PPS in stressed components, additives are usually added, such as glass fiber, carbon fiber, filler, etc. To enhance its mechanical properties, after this modification, the main mechanical properties of PPS, such as tensile properties, bending properties, compression and impact strength, are greatly improved, but the elongation is decreased. The modified PPS can Under the action of long-term load and thermal load, it maintains high mechanical properties and dimensional stability. It is insoluble in any known organic solvents when it is lower than 175 degrees. When PPS is in contact with general organic solvents, plastic parts will not crack.
The mechanical properties of pure PPS are not high, especially the impact strength is relatively low. After being reinforced with glass fiber, the impact strength will be greatly improved, from 27J/m to 76J/m, which will be increased by 3 times; the tensile strength will be increased from 6Mpa to 137Mpa, which will be doubled. PPS has high rigidity, which is rare in engineering plastics. The flexural modulus of pure PPS can reach 3.8Gpa, and after inorganic filling modification, it can reach 12.6Gpa, an increase of 5 times.
PPS is used in the automotive industry accounting for about 45%, mainly used in automotive functional parts; Parts of the lamp holder. It can replace metal to make exhaust cylinder circulation valve, water pump impeller, pneumatic signal conditioner, etc.
Physical Properties |
Metric |
English |
Density |
1.68 g/cc |
0.0607 lb/in³ |
Water Absorption |
0.020 % |
0.020 % |
|
0.030 % |
0.030 % |
Moisture Absorption |
0.250 % |
0.250 % |
Water Absorption at Saturation |
0.26 % |
0.26 % |
Linear Mold Shrinkage, Flow |
0.0020 cm/cm |
0.0020 in/in |
Linear Mold Shrinkage, Transverse |
0.0050 cm/cm |
0.0050 in/in |
Mechanical Properties |
Metric |
English |
Hardness, Rockwell M |
100 |
100 |
Hardness, Rockwell R |
120 |
120 |
Tensile Stress |
200 MPa |
29000 psi |
Elongation at Break |
1.7 % |
1.7 % |
Tensile Modulus |
15.6 GPa |
2260 ksi |
Flexural Strength |
269 MPa |
39000 psi |
|
285 MPa |
41300 psi |
Flexural Modulus |
14.0 GPa |
2030 ksi |
|
14.5 GPa |
2100 ksi |
Compressive Strength |
275 MPa |
39900 psi |
Poissons Ratio |
0.40 |
0.40 |
Shear Strength |
96.0 MPa |
13900 psi |
Izod Impact, Notched |
0.910 J/cm |
1.70 ft-lb/in |
Izod Impact, Unnotched |
6.40 J/cm |
12.0 ft-lb/in |
Izod Impact, Notched (ISO) |
9.00 kJ/m² |
4.28 ft-lb/in² |
Izod Impact, Unnotched (ISO) |
40.0 kJ/m² |
19.0 ft-lb/in² |
Charpy Impact Unnotched |
5.30 J/cm² |
25.2 ft-lb/in² |
Charpy Impact, Notched |
0.880 J/cm² |
4.19 ft-lb/in² |
Application range:
